Setara dengan:
● Eagle Burgmann M2N
● AESSEAL T07D
● Roten 22
Batas Operasi:
● Suhu: -20 derajat - ditambah 180 derajat
● Tekanan: Kurang dari atau sama dengan 10bar
● Kecepatan: Kurang dari atau sama dengan 15m/dtk
● Ukuran Poros: 6mm - 38mm
Bahan:
● Cincin Segel: Karbon Resin, Karbon Antimon, SIC, SSIC, Tungsten Carbide
● Elastomer: VITON, EPDM, NBR, FFKM, AFLAS
● Bagian Logam: SS304, SS316, Duplex, Hastelloy C
Majelis Dwg:
Dimensi (mm):
| D | D3 | D7 | L1 | L3 |
| 6 | 15 | \ | \ | \ |
| 8 | 18 | \ | \ | \ |
| 10 | 20 | 21 | 17.5 | 10.0 |
| 12 | 22 | 23 | 17.5 | 10.0 |
| 14 | 25 | 25 | 17.5 | 10.0 |
| 15 | 27 | 27 | 19.5 | 10.0 |
| 16 | 27 | 27 | 19.5 | 10.0 |
| 18 | 30 | 33 | 20.5 | 11.5 |
| 20 | 32 | 35 | 22.0 | 11.5 |
| 22 | 35 | 37 | 23.5 | 11.5 |
| 24 | 38 | 39 | 25.0 | 11.5 |
| 25 | 40 | 40 | 26.5 | 11.5 |
| 26 | 41 | 40 | 26.5 | 11.5 |
| 28 | 43 | 43 | 26.5 | 11.5 |
| 30 | 47 | 45 | 26.5 | 11.5 |
| 32 | 48 | 48 | 28.5 | 11.5 |
| 35 | 53 | 50 | 28.5 | 11.5 |
| 38 | 56 | 56 | 33.5 | 14.0 |
